Underground Infrastructure Service

FOSS Engineering and Construction Company Limited, an affiliate of our Company that is well recognized by our clients because of their handy work. With their Ground Penetrating Radar (GPR) machine, they complete engineering works, underground cabling construction projects for high to low voltage electrical systems, telecommunications cabling systems, and pipe surveys or underground public utility systems professionally.

Survey

Global Positioning System (GPS) : 2 Machines
Underground Obstacle Surveyer (GPR) : 2 Machines
3D software
2 teams of staff
Surveying
AUTOCAD sample
3D survey images

Global Positioning System (GPS)

Underground obstacle surveyer (GPR)

3D software

AUTOCAD sample

3D survey images

Boreplan

This software program is used specifically for planning to drill surfaces using the information collected from the mapping process to create visible graphics for actual usage from start to finish.

Design Example

Obstacle Example

Design by professional engineers

Material and equipment

HDPE Main Supplier

Thai-Asia P.E. Pipe Co., Ltd.

Microduct Main Supplier

Emtelle Knet

Mline Yofc

HDPE 3 Layers

Pipe factory and HDPE transportation

Microduct transportation

Microduct

HDD

D20 x 22
2 Machines
D23 x 30 S3
3 Machines
D36 x 50 S2
2 Machines
D40 x 55 S3
1 Machine

F5 & Transmitter

HDD Drilling Fluid

Production

Drilling Example

ระหว่าง รูปขุดวาง และ HDD

Summary of Machinery Equipment and Vehicles

HDD Drilling Fluid

*Click for more details

Drilling methods

Using the HDD (Horizontal Directional Boring machine), we are able to drill underground routes for conduits without having to excavate the ground surface. This is suitable for placing conduits with communication cables, telephone cables, gas pipes, plumbing pipes, and pipelines that cross rivers, as these tasks require detailed surveys on the area that is planned to be drilled and underground spaces using the GPR (Ground Penetrating Radar) beforehand to find underground obstacles. Afterwards, the location where the machines will be installed shall be determined. Generally, HDD machines must be installed spaced from each other, and its drilling position must be thoughtfully considered to suit the depth of the pressure well. While drilling, F5 and transmitter machines will also be used to measure the drilling depth, which can be as deep as 30 meters.
